A Three S200

Power Amplifier
Sale price$24,300.00 CAD

Tax excluded.


Discover the embodiment of musicality. The Absolute Amplifier transforms sound into a physical presence, giving music a body that you can feel as much as you hear. Every note takes shape, every chord gains weight, filling your space with a tangible energy. The Absolute Amplifier redefines sound by giving it dimension and depth. Every detail is delivered with stunning precision, from the softest nuances to the most commanding crescendos. It transforms music into an immersive force, making every listening experience unforgettable.

The A Three S200 stereo amplifier from the Absolute line inherits the technology developed by Orpheus Lab for the Opus II of the prestigious Heritage line. It features a current amplification stage driven by six high-power MOSFETs, meticulously hand-matched for each channel, capable of reaching instantaneous current peaks of up to fifteen amperes. To ensure optimal control throughout the amplification chain, each MOSFET is governed by a bipolar technology control stage. This approach, combined with a multi-point feedback topology, allows for the precise application of feedback, achieving a perfect balance between musicality and technical performance. As a result, the A Three S200 adapts seamlessly to any type of loudspeaker.

The Class AB architecture is brought to life by a carefully calibrated 125 mA bias current, delivering a thermal idle power of 15 WPC and allowing the amplifier, at rest, to stabilize at 15 °C above ambient temperature. To guarantee flawless power delivery, each amplification channel is powered by an oversized toroidal transformer with a capacity of 880 VA. The polarization circuit ensures optimal biasing regardless of the operating temperature.

Furthermore, its low impedance BJT component architecture maintains constant biasing irrespective of the load type, even at the highest current peaks. Because musicality comes first and no measuring instrument can rival the human ear in this matter, these technological combinations have been meticulously refined through numerous iterations between laboratory measurements and listening sessions. The result is a purely musical experience, with breathtaking dynamic capability, extremely sharp note attacks, and exceptional openness.



Specs
Input Connections XLR (Balanced) and RCA (Unbalanced)
Input Impedance Balanced: 94 kΩ / Unbalanced: 47 kΩ
Max Input Level 2 Vrms (Balanced) / 1 Vrms (Unbalanced)
Grounding (Unbalanced) Selectable: Grounded or Lifted
Nominal Power (Class AB) 200 W @ 8 Ohm
Peak Instantaneous Power 850 W (<200 ms; Max 56.7 Vpic / 15 Apic)
Bias Current / Idle Power 125 mA / 15 WPC Thermal Idle
Frequency Response 5 Hz – 24 kHz (+0/-0.1 dB); 0.7 Hz – 85 kHz (-3 dB)
THD+N (at 200 W / 8 Ohm) 0.004 % (-88 dB) @ 1 kHz
THD+N (Unloaded) 0.001 % (-100 dB) @ 1 kHz
Clip to Noise Ratio -114 dB (Balanced) / -112 dB (Unbalanced)
Gain 26 dB (Balanced) / 32 dB (Unbalanced)
Output Impedance 0.0 Ohm
Damping Factor > 3000
Amplifier Topology Real dual mono with 6 High-res MOSFETs per channel
Power Supply Dual 880 VA toroidal transformers; 48 mF capacitance
Bias Technology Unique circuit for constant high bias current
Nominal Line Voltage 115 Vac or 230 Vac
Power Consumption 930 W (Maximum)
Dimensions (H x W x D) 148 mm x 440 mm x 420 mm
Weight 30 kg
Overload Protection Non-invasive protection (> 9 Apic / 320 Wpic @ 4 Ohm)
DC Protection Non-invasive protection for frequencies below 5 Hz
Safety Features Automatic Muting on AC line drop or interruption
