CD-1000 MKII
Tax excluded.
The CD-1000 MkII, housed in a beautiful brushed aluminium chassis, integrates a digital and an analogue stage into a single, elegant device. It is designed to listen to music from a CD as well as to play audio files from a TV or DVD player connected via optical or coaxial input.
The CD-1000 MkII delivers a natural, detailed and powerful sound, and can be easily integrated into any Hi-End stereo system. CD-1000 MkII supports Gapless playback and is equipped with a top-of-the-range 24bit/192kHz digital converter and digital inputs such as the S/PDIF coaxial and the TOS optical to get the best out of your system. The aluminium JPL-2800 transport mechanism made in Austria by Stream Unlimited is one of the best in the world and ensures maximum stability avoiding fluctuations or loss of definition. The CD-1000 MkII integrates our Zero-ClockTM technology which allows for an effective reduction of jitter, and features a digital volume control that can be used to drive directly a power amplifier or active speakers.
The CD-1000 MkII is available in three models: CD-1000 MkII equipped with the integrated DAC BurrBrown PCM1796 D/A converter chip; CD-1000 MkII DELUXE equipped with the superior DAC BurrBrown PCM1792A; and CD-1000 MkII DELUXE DSD which additionally features a USB-B port (supporting up to DSD256 and PCM 32bit/384kHz).
The CD-1000 MkII can be paired with external units that allow further improvement of its exceptional audio performance:
– TUBE-1012 and TUBE-1006 – class A valve output stages developed with 6 or 12 valves
– PSU-1250 and PSU-1000 – super inductive external power supply dedicated to the Gold Note series 1000.
Specs |
|
Type | CD transport with integrated D/A converter |
DAC | STANDARD model: 24bit/192kHz DAC PCM1796, DELUXE model: 24bit/192kHz DAC PCM1792A |
Frequency Response | 20Hz–20kHz @ +/-0.3dB |
THD – Total Harmonic Distortion | 0.001% max |
Signal to Noise Ratio | 128dB |
Dynamic Response | 127dB |
Volume Control | Switchable On/Off digital partializer |
Mechanic | Aluminium JPL-2800 Stream-Unlimited |
Speed Fluctuation | 0.00% |
CD Formats | Red Book |
Disc Compatibility | CD, CD-R, CD-RW |
Gapless Playback | Supported |
Remote Control | Multifunctional remote included |
Digital Inputs | 1x RCA S/PDIF coaxial, 1x TOS 24bit/192kHz, 1x USB-B DSD256 and 32bit/384kHz (CD-1000 MKII DSD model only) |
Analogue Outputs | 1x unbalanced RCA, 1x balanced XLR1x, TUBE-1012 |
Digital Outputs | 1x S/PDIF Coax 75Ω |
Output Impedance | 50Ω |
Line Output Level | RCA 2Vrms, XLR 2Vrms |
Power Consumption | 30W |
Power Supply | 100-120V or 220-240V, 50/60HzDual-Mono power supply |
Fuse (220/240V) | 1A F/T |
Fuse (100/120V) | 2A F/T |
Dimensions | 430mm W | 135mm H | 375mm D |
Weight | Kg. 12 – net, Kg. 16 – boxed |
